Desktop Split Fiber Laser Marking Machine

With the rapid development of laser technology, fiber laser marking machines are more and more widely used in various industries. Ordinary fiber laser marking machines can only mark non-black and white marks, which are very single and colorless.


Fiber laser marking machine is a commonly used laser marking machine on the market. It mainly emits light through a laser. After the integrated beam reacts with the surface of the object at a suitable position, the corresponding text symbols are etched on the surface of the object.

It has a wide range of applications, including daily hardware materials, kitchen utensils, surgical machinery, auto parts, gold and silver jewelry, plastic pipes, leather, electronic components, lacquer materials and so on.

JPT Mopa fiber laser printing machine for Stainless steel Colorful marking
JPT Mopa fiber laser printing machine for Stainless steel Colorful marking

Video introduction

Tech Specifications

Laser types Fiber laser generator
Laser power 20W/30W/50W/100W
Laser source brand Raycus
Optical quality <0.5
Laser wavelength 1064nm
Standard marking area 110 x 110 mm
Optional marking area 150x150mm, 200x200mm, 300x300mm
Working table Aluminum alloy working table
Working speed 7000mm/s
Positioning accuracy ±0.01mm
Laser frequency 1-4000kHz
Control system Digital offline control system( USB Controller)
Cooling system Air cooling
Power supply AC220V ± 5% 50/60HZ / AC110V, 60HZ
Support operation system Win7/8/10 system
Format supported AI , BMP, PLT, DXF, DST , PCX, JPG etc.
Machine size 73x48x54cm
Gross weight 55KG
Optional collocation Rotary attachment
Gross power ≤800W
Working temperature 0-40℃

Application materials

Fiber laser markers are a great way to expand your marking capabilities and improve the quality of your marking results on certain plastics and metals. Using traditional printing methods, it is difficult to leave the corresponding permanent marking machine on the object without destroying the surface of the object, but the laser marking machine can.

Laser marking machines can be applied to metals, stainless steel, aluminum, alumina, copper, gold and silver, hard plastics, lacquer materials, ceramics, circuit boards, etc.

JPT Mopa fiber laser printing machine for Stainless steel Colorful marking


1.What is your main processing requirement? Laser cutting or laser engraving (marking) ?
2. What material do you need to laser process?
3. What is the size and thickness of the material?
4. Your company name, website, Email, Tel (WhatsApp…)?Are you reseller or need it for your own business?
5. How do you want to ship it , by sea or by express , whether do you have your own forwarder?
